AtomMek Static Mixers – Precision Inline Mixing Without Moving Parts
Why Choose AtomMek Static Mixers?
Static mixers offer a robust, energy-efficient solution for continuous inline mixing. With no moving parts, they ensure low maintenance and consistent product results.
No Moving Parts – Minimal Maintenance
No wear or mechanical breakdown means longer equipment lifespan and reduced downtime.
Continuous Inline Operation
Ideal for continuous dosing, reaction, or blending directly within pipelines.
Enhanced Product Uniformity
Delivers high mixing performance even for fluids with different viscosities, densities, or phases.
How Do Static Mixers Work?
Static mixers use a fixed internal geometry (mixing elements) to split, rotate, and re-blend fluid streams multiple times as they flow through the pipe.
The Process Steps
- Fluid Entry: Two or more streams enter the mixer.
- Flow Division & Mixing: Internal elements cut and fold flow.
- Homogenization: Uniform output with minimal energy input.
Applications of AtomMek Static Mixers
- Chemical Mixing (Additives, pH Neutralization)
- Water Treatment (Chlorination, Coagulation)
- Food & Beverage (Flavors, Syrups, Enzymes)
- Petrochemical & Refining
- Paints, Coatings, Inks
- Pharmaceutical & Cosmetic Formulations
Construction & Customization Options
Available in Carbon Steel or Stainless Steel (AISI 304/316L)
Pipe Sizes: DN15 to DN500
Connections: Flanged / Tri-clamp / Threaded
Installation: Horizontal or Vertical
Technical Specifications
Model | Pipe Diameter | Flow Rate (m³/h) | Material | Elements | Viscosity Range |
STM-25 | 25 mm | 0.5 – 2.5 | SS316L / CS | Helical | Low–Medium |
STM-50 | 50 mm | 2 – 5 | SS316L / CS | Helical / X-type | Medium–High |
STM-100 | 100 mm | 5 – 15 | SS316L | Helical | High |
Certifications & Quality Assurance
- ISO 9001
- CE Certification
- SGS Testing Available
