AtomMek Planetary & Double Planetary Mixers:
Precision Mixing for High-Viscosity & Specialty Applications Mix Thick, Sticky, or Delicate Materials with Accuracy & Efficiency
AtomMek Planetary & Double Planetary Mixers
The Ultimate Solution for Complex Mixing Challenges
Designed for exceptional precision in high-viscosity and specialty applications, AtomMek Planetary Mixers offer effective agitation for materials that conventional mixers cannot handle. From thick pastes and adhesives to fine powders and delicate fibers, our mixers offer unparalleled control, uniformity, and performance.
Why Choose AtomMek Planetary Mixers?
Thorough Vertical & Orbital Motion
Dual blades rotate on their axes while orbiting the vessel, ensuring every point in the batch is contacted.
No Shaft Seals in Product Zone
Vertical design prevents contamination and simplifies cleaning, ideal for sterile or high-purity applications.
Vacuum & Pressure Ready
Precision-machined vacuum covers allow for degassing, drying, and sensitive material processing.
Easy Vessel Exchange
Hydraulic lifts and change-can systems enable semi-continuous operation and faster batch turnover.
Features at a Glance
Superior Efficiency & Repeatability
- Powerful kneading action ideal for ultra-thick or shear-sensitive materials
- Smooths agglomerates and ensures high batch uniformity
Fully Customizable Configurations
- High Viscosity (HV), Rectangular, or Finger blades for different applications
- Available with heating/cooling jackets, vacuum hoods, and interchangeable vessels
Scalable From Lab to Production
- Sizes from 1L to 3,000L
- Perfect for R&D, pilot trials, and industrial production
Typical Applications
- Epoxy Adhesives
- Dental & Ceramic Pastes
- Conductive Inks & Battery Slurries
- Silicones & Sealants
- Wet Granulations in Pharma
- Pigments, Putty, Grease
Technical Specifications
Model | Motor (kW) | Volume (L) | Blade Type | Vacuum Capability | Lift System | Material | Options |
PPM-10 | 2.2 | 10 | HV / Rectangular | Yes | Manual | SS316L | Jacketed vessel |
PPM-50 | 5.5 | 50 | HV / Finger | Yes | Hydraulic | SS316L | Load cells, PLC |
PPM-200 | 15 | 200 | HV / Rectangular | Yes | Hydraulic | SS316L | Spray bar, CIP |
DPM-500 | 30 | 500 | HV Blades | Yes | Hydraulic | SS316L | VFD, HMI Panel |
Certifications
All AtomMek mixers meet global compliance standards:
- ISO 9001
- CE Marked
- SGS Certified (on request)
Available Series
- Laboratory Series: Compact mixers for R&D and small-batch production
- Production Series: Robust units for industrial-scale continuous or batch mixing
- Vacuum Series: Sealed systems for degassing, drying, and reactive ingredients
Visual Gallery & Video Demonstrations
- High-resolution photos showcasing blade types and lift systems
- Mixer in action: see full batch turnover in seconds
- Installations across the pharma, adhesives, and sealant industries
Additional Resources
- How to Choose Between Planetary & Double Planetary Mixers
- Tips for Granulation & Degassing in Planetary Systems
- Blade Configuration Guide
